ROBACERAM
Ceramic dewatering elements

ROBACERAM dewatering elements

Optimized design. Lower drive power.
Safest machine operation.

ROBACERAM dewatering elements consist of a special composite of high-performance ceramics and glass-reinforced plastic. Both components are joined together by a mechanical form fit. Compared to plastic elements, ceramic dewatering elements are many times more resistant to wear. This makes them ideally suited for the highest stresses and fastest machine speeds.

Why to choose ROBACERAM dewatering elements?

What makes ROBACERAM so special:

Safest interconnected
system

The special form fit of the design guarantees the most stable and secure bond between FRP and ceramic. This prevents step formation and guarantees the safest machine operation.

Infinite design possibilities

The custom development of products at Röchling enables unique product designs for specific challenges.

For highest demands

Machine speeds of up to 3,000 m/min possible in modern paper machines.



Do you need advice or want more information?

Book an appointment now with our product manager Markus Magauer.

Book your Teams-Call

Material designs

ROBACERAM® ALOX

Technically high-quality ceramics with the best price-performance ratio.

_ High purity (99.7 % AO)
_ Good material hardness
_ Good wear resistance


DEPLOYMENT LOCATION:

Up to approx. 800 m/min – entire wire section // Up to approx. 1,200 m/min – from the wire table to the waterline



ROBACERAM® ZTA

Special ceramics for special applications with higher filler content.

_ Thermal shock resistance of 180° C
_ Improved surface
_ Small grain structure


DEPLOYMENT LOCATION:

Up to approx. 800 m/min – entire wire section // Up to approx. 1,200 m/min – from the wire table to the waterline // Vacufoils & formers, flat suction boxes for higher filler content


ROBACERAM® ZIROX

Special ceramics in the area of the press section.

_ Thermal shock resistance of 200° C
_ Low hardness
_ Tough material
_ Low porosity


DEPLOYMENT LOCATION:

Up to approx. 800 m/min – for press section // Not recommended for former elements



ROBACERAM® SIN

Premium nitride ceramic with needle-shaped grain structure and very good surface quality.

_ Very high thermal shock resistance of 600° C
_ Good wear resistance
_ Good surface quality
_ Tough material


DEPLOYMENT LOCATION:

Up to approx. 800 m/min – with GAP formers // Up to 1,500 m/min – for fourdrinier machines // for all positions in modern paper machines (from gravitational dewatering)


ROBACERAM® SIC

Liquid phase sintered premium silicon carbide with highest wear resistance.

_ Best price-performance ratio
_ Extremely good wear resistance
_ Good surface quality
_ Highest hardness


DEPLOYMENT LOCATION:

Up to approx. 3,000 m/min – for all highly and extremely stressed positions in modern paper machines, in particular for all areas with high vacuum


ROBACERAM® SL200B

Special nitride with additionally improved surface finish and increased hardness.

_ Very high thermal shock resistance of 600° C
_ Increased wear resistance compared to SIN
_ Very smooth surface
_ Promotes high wire life


DEPLOYMENT LOCATION:

Up to approx. 3,000 m/min – for all highly and extremely stressed positions in modern paper machines, in particular for all areas with high vacuum



ROBACERAM® PX

Special hybrid ceramic with completely closed surface and highest mechanical properties.

_ Highest thermal shock resistance of 700° C
_ Reduction of drive power (ENERGY SAVER)
_ Maximum wire life
_ Extremely smooth surface (zero porosity)
_ Energy saving up to 30 %


DEPLOYMENT LOCATION:

_ Up to approx. 3,000 m/min – for all highly and extremely stressed positions in modern paper machines, in particular for all areas with high vacuum



Need a service for your ceramic dewatering elements?

Or do you need an inspection, maintenance or repair? Then you are at the right place at ROBASERV
where we provide excellent advice with our certified service teams.
