Trovidur® NL red
PVC-U
T-20 red
welding rod
Characteristics
- Identification colour red
- Uniform physical properties
- Good resistance to acids, lyes and salt solutions
- Flame retardant
- Self-Extinguishing after removal of the flame
- Good weldability
- Good thermoformability
- Good glueability
- Good impact strength
Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Stock item (no MOQ) | 101314 | Trovidur® NL red extruded | welding rod | welding rod | T-20 red | Ø 3 x 1.000 mm | 1,000 mm | 3 mm | |||
| Stock item (no MOQ) | 101315 | Trovidur® NL red extruded | welding rod | welding rod | T-20 red | Ø 4 x 1.000 mm | 1,000 mm | 4 mm |
Technical Specifications Trovidur® NL red
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,40 |
| Water absorption | DIN EN ISO 62 | % | 0,20 |
| Flammability (Thickness 1 … 3 mm) | DIN 4102 | B1 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 62 |
| Elongation at break | DIN EN ISO 527 | % | 15 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 3000 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | 2 |
| Shore hardness | DIN EN ISO 868 | scale D | 85 |
| Ball Hardness | ISO 2039 | MPa | 125 |
| Compressive strength | DIN EN ISO 604 | MPa | 70 |
| Bending strength | DIN EN ISO 178 | MPa | 80 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Thermal conductivity | DIN 52612-1 | W / (m * K) | 0,16 |
| Vicat softening temperature | DIN EN ISO 306, Vicat B | °C | 76 |
| Service Temperature | °C | -10 ... +60 | |
| Heat deflection temperature | DIN EN ISO 75 | °C | 69 |
| Coefficient of linear thermal expansion | DIN EN ISO 11359-2 | mm/m K | ∼ 0,075 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Dielectric constant | IEC 60250 | 3,2 | |
| Dielectric dissipation factor (106 Hz) | IEC 60250 | 0,02 | |
| Volume resistivity | DIN EN 62631-3-1 | Ω * cm | >1015 |
| Surface resistivity | DIN EN 62631-3-2 | Ω | >1013 |
| Dielectric strength | IEC 60243 | kV / mm | 12 |
| Comparative tracking index | IEC 60112 | CTI | 600 |
