Test Method | Unit | Guideline Value | |
---|---|---|---|
Density | ISO 1183 | g / cm3 | 1,85 |
Flexural strength ┴ | ISO 178 | MPa | 360 |
Modulus of elasticity in flexion ┴ | ISO 178 | MPa | 20000 |
Compressive strength ┴ | ISO 604 | MPa | 500 |
Tensile strength II | ISO 527 | MPa | 280 |
Impact strength II (Charpy) | ISO 179 | kJ / m2 | 100 |
Test Method | Unit | Guideline Value | |
---|---|---|---|
Coefficient of linear expansion II | TMA (Mettler) | 10-6 x K-1 | 10 - 20 |
Temperature index | IEC 60216 | T.I. | 180 |
Insulation class | IEC 60085 | / | H |
Test Method | Unit | Guideline Value | |
---|---|---|---|
Water absorption (4mm thickness) | ISO 62 | % | 0,2 |
Test Method | Unit | Guideline Value | |
---|---|---|---|
Electric strength 90°C under oil ┴ | IEC 60243 | kV / mm | 13 |
Electric strength 90°C under oil II | IEC 60243 | kV/25mm | 70 |
Relative permittivity (50 Hz) | IEC 60250 | εr | 5 |
Specific surface resistance | IEC 60093 | Ω | 1013 |
Specific volume resistance | IEC 60093 | Ω x cm | 1014 |
Comparative tracking index | EN 60112 | CTI | 400 |
