Technical Specifications Robaflow® S
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,06 |
| Flammability | UL 94 | HB | |
| Moisture Absorption (23°C, 50% RH) | DIN EN ISO 62 | % | 0,06 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 30 |
| Elongation at break | DIN EN ISO 527 | % | >50 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 1500 |
| Notched impact strength | ISO 179-1/1eA | kJ / m2 | 17 |
| Shore hardness | DIN EN ISO 868 | scale D | 78 |
| Ball indentation hardness (H358/30) | DIN EN ISO 2039-1 | MPa | 70 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Coefficient of linear thermal expansion | DIN 53752 | 10-6 / K | 70 - 90 |
| Vicat softening temperature | DIN EN ISO 306, Vicat B | °C | 115 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Dielectric constant | IEC 60250 | 2,7 | |
| Volume resistivity | DIN EN 62631-3-1 | Ω * cm | 1015 |
| Surface resistivity | DIN EN 62631-3-2 | >1015 |
