LubX® AST black

PE — PE-UHMW - PE 1000

black, similar RAL 9005
profilesheet
QR-Code

Characteristics

  • Antistatic
  • Good dry-running properties
  • Good wear resistance
  • Good sliding properties

Industries

Application Examples

+

Sliding elements for conveyor systems

Our LubX® product range offers high-performance sliding materials specifically developed for conveyor technology. Thanks to its outstanding sliding properties, conveyor systems equipped with LubX® need less energy, slip-stick effects are avoided and process stability is improved. Depending on the application we recommend LubX® CV, LubX® C, LubX® S or LubX® Ast black.

+

Slide rails for spiral frosters

Profiles made of our material LubX® are used in the construction of spiral frosters for frozen pizzas. With its outstanding slide properties, the material helps to reduce the conveying power required and hence the energy used. LubX® meets the requirements of Regulation 10/2011/EU and the FDA and so is suitable for direct contact with foodstuffs. Depending on the application we recommend LubX® CV, LubX® C, LubX® S or LubX® Ast black.

+

Slide elements for beverage bottling plants

Our LubX® product range offers heavy-duty sliding materials specifically developed for conveyor technology. Thanks to its outstanding slide properties, conveyor systems equipped with LubX®, such as those in beverage bottling plants, need less energy, slip-stick effects are avoided and the stability of the conveyor processes is improved. Depending on the application we recommend LubX® CV, LubX® C, LubX® S or LubX® Ast black.

Variants

SKUNameTypeTypeColorMeasurementsLengthWidthThicknessHeight
No stock item (MOQ)		373451LubX® AST black extruded Special profile Special profile (R593) black, similar RAL 900530.000 x 11,5 x 12 mm 30,000 mm 11.5 mm 12 mm
No stock item (MOQ)		418756LubX® AST black extruded Special profile Special profile (R699) black, similar RAL 90056020 (-0/+30) x 18,4 x 6 mm 6,020 mm 18.4 mm 6 mm
No stock item (MOQ)		460446LubX® AST black extruded Special profile Special profile (R779) black, similar RAL 90053000 (-0/+30) x 17 x 6,2 mm 3,000 mm 17 mm 6.2 mm
No stock item (MOQ)		464768LubX® AST black extruded Special profile Special profile (R789) black, similar RAL 90053020 (-0/+30) x 7,95 x 5 mm 3,020 mm 7.95 mm 5 mm
No stock item (MOQ)		471221LubX® AST black extruded Special profile Special profile (R779) black, similar RAL 90056000 (-0/+20) x 17 x 6,2 mm 6,000 mm 17 mm 6.2 mm
No stock item (MOQ)		380271LubX® AST black pressed sheet sheet black, similar RAL 90052.000 x 1.000 x 15 mm 2,000 mm 1,000 mm 15 mm
No stock item (MOQ)		401972LubX® AST black pressed sheet sheet black, similar RAL 90052.000 x 1.000 x 50 mm 2,000 mm 1,000 mm 50 mm
No stock item (MOQ)		443420LubX® AST black pressed sheet sheet black, similar RAL 90052.000 x 1.000 x 20 mm 2,000 mm 1,000 mm 20 mm
No stock item (MOQ)		443440LubX® AST black pressed sheet sheet black, similar RAL 90056000 x 2000 x 20 mm 6,000 mm 2,000 mm 20 mm
No stock item (MOQ)		450813LubX® AST black pressed sheet sheet black, similar RAL 90056.000 x 2.000 x 25 mm 6,000 mm 2,000 mm 25 mm
No stock item (MOQ)		463802LubX® AST black pressed sheet sheet black, similar RAL 90056000 x 2000 x 15 mm 6,000 mm 2,000 mm 15 mm

Technical Specifications LubX® AST black extruded

Test MethodUnitGuideline Value
DensityDIN EN ISO 1183-1g / cm30,94
Water absorptionDIN EN ISO 62%0,01
Flammability (Thickness 3 mm / 6 mm)UL 94HB
Test MethodUnitGuideline Value
Yield stressDIN EN ISO 527MPa20
Elongation at breakDIN EN ISO 527%>50
Tensile modulus of elasticityDIN EN ISO 527MPa650
Notched impact strengthDIN EN ISO 179kJ / m2no break
Shore hardnessDIN EN ISO 868scale D60
Test MethodUnitGuideline Value
Melting temperatureISO 11357-3°C133 – 135
Coefficient of linear thermal expansionDIN 5375210-6 / K150 - 230 (*)
Service temperature, long termAverage°C-150 … 80 (*)
Service temperature, short term (max.)Average°C130 (*)
Test MethodUnitGuideline Value
Surface resistivityDIN EN 62631-3-2Ω 109

Technical Specifications LubX® AST black pressed

Test MethodUnitGuideline Value
DensityDIN EN ISO 1183-1g / cm30,94
Water absorptionDIN EN ISO 62%0,01
Flammability (Thickness 3 mm / 6 mm)UL 94HB
Test MethodUnitGuideline Value
Yield stressDIN EN ISO 527MPa20
Elongation at breakDIN EN ISO 527%>50
Tensile modulus of elasticityDIN EN ISO 527MPa650
Notched impact strengthDIN EN ISO 179kJ / m2no break
Shore hardnessDIN EN ISO 868scale D60
Test MethodUnitGuideline Value
Melting temperatureISO 11357-3°C133 – 135
Coefficient of linear thermal expansionDIN 5375210-6 / K150 - 230 (*)
Service temperature, long termAverage°C-150 … 80 (*)
Service temperature, short term (max.)Average°C130 (*)
Test MethodUnitGuideline Value
Surface resistivityDIN EN 62631-3-2Ω 109
