A new version of RITA® 4.0

Start menu: The user interface of RITA®4.0 is simple and intuitive to operate

Wind load map: As one of its new functions, RITA®4.0 now offers interactive wind and snow load maps – users select the location of the tank and the wind and snow loads are automatically incorporated into the calculation

New methods of calculation combined with proven flexibility: RITA®4.0 offers a completely new method of calculation for rectangular tanks – the results of calculations can be modified and optimised using a simple and intuitive menu function

New function: Users can use the new steel profile management tool to store individual profiles in the system and incorporate them into the calculation

Röchling has made major updates to its proven software for tank calculation

With RITA® 4.0 Röchling Engineering Plastics SE & Co. KG, Haren/Germany, is now offering a new, updated version of its proven tank calculation programme. The programme "RITA® 4.0 - Röchling's Integrated Tank building Assistant", which has been tested by TÜV Nord, calculates free standing, pressureless circular and rectangular tanks under consideration of the current DVS-standards. Now with several new functions, RITA® 4.0 facilitates the dimensioning of rectangular tanks and contributes significantly to planning safe and economic tanks.

Anniversary news: 15 years ago Röchling first introduced its tank calculation programme RITA® – Röchling’s Integrated Tank building Assistant, developed along with TÜV NORD. Today tank builders from more than 30 countries rely on the market-proven programme for calculating and designing rectangular and round tanks made from thermoplastics, including customers in Australia, Japan, China, Israel and India. RITA® provides users with a pre-testable static printout containing all of the information needed for the approval of a tank.

For the development of the new version, Röchling spoke with numerous users of the previous version all over the world and incorporated their experiences and suggestions into the revised version. RITA® 4.0 takes full account of the newest technological developments and requirements for the construction of thermoplastic tanks. The new version was reviewed by TÜV Nord, as were the previous versions. The awarding of TÜV's quality seal confirms the reliability of calculations made with RITA®.

New calculation methods for rectangular tanks

One of the main innovations of RITA® 4.0 is the optimized calculation of rectangular tanks with all-around and yoke reinforcement. This process uses an entirely new analytical calculation method: Röchling has developed a new formula apparatus based on numerous calculations with the help of the Finite Element Method (FEM). Thomas Schüer, Marketing & Development at Röchling and responsible for the area "chemical processing industry" has been overseeing RITA® for 10 years. He explains: "The newly developed formulas help builders to design their tanks in a more economical way, in particular because the new calculations allow for significantly smaller steel profiles."

Individual specifications

Rectangular tank planning has also been simplified by the new option of specifying the minimum wall thickness for specific types of tanks in the programme. RITA® 4.0 calculates the necessary steelwork for a given wall thickness. At the same time, users can use the new steel profile management tool to store individual profiles in the system and incorporate them into the calculation. "These functions help tank builders to plan rectangular tanks in a way that is more flexible and tailored to individual needs," explains Schüer.

Changes to guideline DVS 2205 for round tanks.

For the calculation of round tanks, RITA® 4.0 takes into account current changes to guideline DVS 2205. These include the current safety concept, calculation of the static load of a platform in roof superstructures and an optimised nozzle calculation that users can use to incorporate the wall thickness of the nozzle tube into the calculation in RITA® 4.0.

Wind load and snow load

For the first time, interactive wind and snow load maps are available in RITA® 4.0 especially for the planning and design of outdoor tanks. On a map, users select the planned location of the tank and the corresponding wind and snow loads are factored into the calculation. Maps are available for numerous European countries, including Germany, France, the Netherlands and the Czech Republic.

Additional innovations in RITA® 4.0 include a miner tool for calculating the average temperature in a tank, an expansion of the material database and optimisation of static printouts.

Free training and service

"We want to make the calculation of thermoplastic round and rectangular tanks as easy as possible for our users," says Schüer of the new functions. In addition to high functionality, Röchling placed great importance on user experience in the programme's design. According to Schüer, "we offer our users standard free technical service via the team viewer. We do not charge maintenance fees. We are also happy to provide training sessions on request."

Röchling has designed a very user-friendly license model. RITA® 4.0 comes standard-equipped with a multi-user license. "This means that several users can easily work with one license based on their location," explains Schüer. A free demo of the new version is available on request. RITA® 4.0 is available in German, English, French and Czech.

Complete system for tank construction

The tank calculation programme RITA® 4.0 is part of Röchling's extensive offering for the construction of chemical tanks and plants. An international plastics processor, Röchling offers one of the largest range of products and services for chemical tank and plant construction, from sheet material, tubes, U-profiles and welding rods to the tank calculation software RITA and expert advice in selecting the proper material. Röchling has extensive databases and many years of experience in the chemical resistance of thermoplastics.


Contact

We are happy to provide you with information on the new functions and advantages of RITA® 4.0.

Just write to: ➜ Inquiry: RITA® 4.0


More information about RITA® 4.0
