SustaPVDF - ASTM
PVDF
Characteristics
- High purity
- High tensile strength
- High stiffness
- High cold impact strength
- Good weldability
- High continuous service temperature
- Electrically insulating
- Chemical resistant
- Good weather resistance
Industries
Semiconductor Front-End Wet Bench
Technical Specifications SustaPVDF - ASTM
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | ASTM D792 | g / cm3 | 1.78 |
| Water Absorption 24 hours | ASTM D570 | % | 0.03 |
| Dissipation Factor | ASTM D150 | 1MHz | 0.06 |
| Water Absorption Saturation | ASTM D570 | % | 0.05 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Hardness | ASTM D2240 | Shore D | 77 |
| Tensile Strength at yield 73°F | ASTM D638 | psi | 7000 |
| Tensile Modulus | ASTM D638 | psi | 250000 |
| Elongation at Break | ASTM D638 | % | 100 |
| Flexural Strength | ASTM D790 | psi | 8000 |
| Flexural Modulus | ASTM D790 | psi | 290000 |
| Compressive Strength | ASTM D695 | psi | 10500 |
| Rockwell Hardness | ASTM D785 | 75 | |
| Rockwell Hardness | ASTM D785 | R | 84 |
| Izod Impact, Notched | ASTM D256 | ft-lb/in | 3 |
| Coefficient of Friction, Dynamic | 0.58 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Thermal Conductivity | in/hr/ft2 /°F | 0.75 | |
| Coefficient of Linear Thermal Expansion | ASTM D696 | in/in/°F x10-5 | 6.6 |
| Melting Point | ASTM D789 | °F | 335 |
| Continuous Service Temperature, Air | °F | 300 | |
| Deflection Temperature at 1.8Mpa (264psi) | ASTM D648 | °F | 230 |
| Deflection Temperature at 1.8Mpa (66psi) | ASTM D648 | °F | 270 |
| Flammability, UL94 | 1/8 inch | V-0 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Dielectric constant | ASTM D150 | 1MHz | 8.5 |
| Dielectric strength | ASTM D149 | V/mil | 1600 |
| Surface resistivity | ASTM D257 | Ω/cm | >1013 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| FDA | Yes | ||
| NSF | No | ||
| USDA | Yes |
