Technical Specifications Durostone® EPF S1

Test MethodUnitGuideline Value
DensityISO 1183g / cm31,85
Flexural strength ISO 178MPa340
Modulus of elasticity in flexion ISO 178MPa24000
Compressive strength ISO 604MPa350
Compressive strength IIISO 604MPa180
Tensile strength IIISO 527MPa300
Impact strength II (Charpy)ISO 179kJ / m250
Shear strength IIIEC 60893MPa30
Test MethodUnitGuideline Value
Temperature indexIEC 60216T.I.155
Insulation classIEC 60085/F
Test MethodUnitGuideline Value
Water absorption (4mm thickness)ISO 62% 0,1
Test MethodUnitGuideline Value
Electric strength 90°C under oil IEC 60243kV / mm10
Electric strength 90°C under oil IIIEC 60243kV/25mm35
Relative permittivity (1 MHz)IEC 60250εr5,5
Dielectric loss factor (50 Hz)IEC 60250tan δ0,04
Comparative tracking indexIEC 60112CTI180
Insulation resistance after 24 h water immersionIEC 60167Ω5 x 1010
